HDCVI 1080p 4ch DVR
- 1000GB to 8000GB HDD Options
- 1080p Realtime Recording
- Supports HDCVI, IP & Analogue Inputs
- 1080P Live Real Time Display
- ONVIF Compatible
- Includes Dahua Smart PSS
- Dedicated Dahua App
- Free DDNS Hosting
- HDMI/VGA Outputs
- Audio Recording
- Smart Search Facility
- USB/Network Backup
- Immix Compatible
- Fully UK Tested
- Size: 375 x 285 x 55mm
Specification
Model Number: HCVR7204A-V2
System
Main Processor: Embedded processor
Operating System: Embedded LINUX
Video
Input: 4 channel, BNC
Standard: HDCVI: 1080P/720P HDCVI Camera Analog: NTSC(525Line, 60f/s), PAL(625Line, 50f/s) IP: 1080P/720P/D1/CIF IP Camera
IP Camera Limit: 2 Channels up to 16Mbps total, Maximum Resolution 1080P
Audio
Input: 4 channel, RCA
Output: 1 channel, RCA
Two-way Talk: Reuse audio input/output channel 1
Display
Interface: 1 HDMI, 1 VGA
Resolution: 1920×1080, 1280×1024, 1280×720, 1024×768, 800×600
Display Split: 1/4
Privacy Masking: 4 rectangular zones (each camera)
OSD: Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio Compression: H.264/G.711
Resolution: 1080P(1920×1080)/720P(1280×720)/960H(960×576/960×480)/D1/4CIF( 704×576/704×480)/CIF(352×288/352×240)/QCIF(176×144/176×120)
Record Rate: Main Stream:: 1080P/720P/960H/D1/HD1/2CIF/CIF(1~25/30fps) Extra Stream: CIF/QCIF(1~25/30fps),D1(1~12/15fps)
Bit Rate: 48~6144Kb/s
Record Mode: Manual, Schedule(Regular(Continuous), MD), Stop
Record Interval: 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger Events: Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Spot, Snapshot, Buzzer & Screen tips
Video Detection: Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input: 4 channel
Relay Output: 3 channel
Playback & Backup
Sync Playback: 1/4
Search Mode: Time/Date, MD & Exact search (accurate to second)
Playback Functions: Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file,
Playback Functions: Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode: USB Device/Network
Network
Ethernet: RJ-45 port (10/100M/1000M)
Network Functions: HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P
Max. User Access: 128 users
Smart Phone: iPhone, iPad, Android
Storage
Internal HDD: 2 SATA ports, up to 8TB
Auxiliary Interface
USB Interface: 2 ports (1 Rear), USB2.0
RS485: 1 port, For PTZ control
General
Power Supply: DC12V/5A
Power Consumption: 15W(without HDD)
Working Environment: -10°C ~+55°C / 10%~90%RH / 86~106kpa
Dimensions: 1U, 375mm×285mm×55mm
Weight: 2.35KG(without HDD)
Camera Specifications
HDCVI 1080P IR Mini Dome Lite
- 3.6mm Fixed Lens
- 1/2.7″ 2Mp CMOS
- 25/30fps @ 1080p
- Day/Night with IR Cut
- 20m Smart IR Range
- Up to 200m range using RG59
- AWB, AGC, BLC & 2D-DNR
- Works with analogue ancillaries
- Manage via Dahua Software
- Configure via DVR interface
- IP66 Rated
- Size: Ø 94 x 79.5mm
Model Number: HAC-HDW1200M-360
Image Sensor: 1/2.7″ CMOS
Resolution: 2 Megapixel
Effective Pixels: 1930×1088
Electronic Shutter Speed: 1/50 – 1/100,000s
Minimum Illumination: 0 Lux
HD/SD switchable: No
IR LEDs: Yes
IR Cut: Yes
IR LED Range: 20m
Smart IR: Yes
Noise Reduction: 2D
Lens Size: 3.6mm
Focus Control: Fixed
Angle of View: 80.6°
Lens Type: Fixed Iris
Input Voltage: DC 12v
Power Consumption: 2.5W Max
Working Environment: -30° – +60° <95% Humidity
IP Rating: IP66
Vandal Resistence: N/A
Dimensions: 94×79.5mm
Weight: 0.35Kg
